Beiben 2638 short cabin dump truck is a highly reliable and efficient vehicle, widely used in the Democratic Republic of Congo (DRC) for various heavy-duty applications. Equipped with the WP10.380 engine, 9JS160A transmission, Q345B steel cargo box, China’s famous HYVA lifting system, and robust 12.00R20 tyres, beiben 2638 dump truck offers exceptional performance in challenging working environments. Its main applications in the DRC can be summarized as follows:
Mining Operations: The Beiben 2638 short cabin dump truck is extensively used in the DRC’s mining sector, renowned for its rich deposits of copper, cobalt, and other minerals. Its powerful WP10.380 engine and durable Q345B steel cargo box enable it to carry heavy minerals and ores from mining sites to processing facilities over tough terrains.
Biben NG80B short cabin dump truck in great quantity
Beiben 30 Ton dump truck for exporting
Desert filtering system for beiben 2638 dump truck
Construction Projects: In urban development and infrastructure construction, such as roads, bridges, and buildings, the truck’s reliable 9JS160A transmission ensures smooth gear shifts and efficient transport of sand, gravel, stone, and construction debris.
Rural and Off-road Hauling: The robust 12.00R20 tyres and sturdy chassis allow the Beiben 2638 to operate efficiently on rugged, unpaved roads often found in rural areas of Congo.
|
Beiben 2638 dump truck |
||
|
General |
Vehicle Brand |
CEEC TRUCKS |
|
Chassis Brand |
Beiben |
|
|
Overall Dimension |
8500*2500*3430 mm |
|
|
GVW / Kerb Weight |
40,000 kg / 12,500 kg |
|
|
|
||
|
Cab |
Cab Capacity |
3 persons allowed |
|
Air Conditioner |
Heating/cooling air conditioner |
|
|
Engine |
Fuel Type |
Diesel |
|
Engine Brand |
WEICHAI, WD12.420 |
|
|
Power |
380 HP (279 KW) |
|
|
Displacement |
9726 ml |
|
|
Emission Standard |
Euro 3 |
|
|
|
||
|
Chassis |
Drive Type |
6X4, left hand drive |
|
Transmission |
FAST 9 speed levers with 1 reverse |
|
|
Wheelbase/No. of axle |
4100+1450 mm / 3 |
|
|
Tire Specification |
12.00R24 |
|
|
Tire Number |
10 tires and 1 spare tire |
|
|
Max Speed |
90 km/h |
|
|
Paint |
Automatic Metallic paint |
|
|
|
||
|
Super structure |
Cargo box |
5600x2300x1500 |
|
shape |
Common heavy duty |
|
|
Material |
Carbon steel, Q345B |
|
|
Side thickness |
4 mm |
|
|
Bottom thicknes |
6 mm |
|
|
Optional |
NOTE: a) All standard accessories: In-cab controls, ladder, anti-static belt, fire extinguisher, inlet valve, discharge valve, Hose & Hose box, Backup alarm, LED lights, reflectors and mud flaps, water level gauge, pressure gauge b) Tank material: Available in carbon steel, stainless steel and aluminum, |
|
Beiben 2638 dump truck, Your first choice
Beiben 2638 dump truck chassis is famous for its NG80B short day cabin, very durable for its mercedes benz technlogy and Benz technlogy frame, with WEICHAI EURO 3 diesel engine, suitable for africa congo weather and road situation.
Super rigid dump truck
With more than 20 years on heavy duty truck chassis designing, beiben 2638 dump trucks with full blood heritage of benz trucks. The truck main frame is originally from germany benz technology , 30% stronger than china domesitic heavy truck factory.
