Двигатель Weichai WP12 420 для грузовика Beiben
Двигатель Weichai WP12.420E32 — это рядный шестицилиндровый четырехтактный дизельный двигатель серии Weichai Power WP12 с водяным охлаждением и промежуточным охлаждением, рабочим объемом около 11,596 л, максимальной мощностью 420 л.с. (приблизительно 309 кВт) и максимальным крутящим моментом около 1750 Н·м. Он отличается компактной и прочной конструкцией, хорошей топливной экономичностью и широко используется в машиностроении и транспортной отрасли, например, в большегрузных автомобилях и тракторах.
Размеры (мм):
1650×820×1100mmМощность двигателя:
420HPЗамечание:
Brand new WP12 series enginesОн Weichai WP12.420E32 engine adopts an electronically controlled high-pressure common rail injection system and a turbocharged intercooled intake. It has a compact structure, good fuel economy, and strong adaptability. It is an inline 6-cylinder, water-cooled, four-stroke turbocharged intercooled diesel engine with a displacement of approximately 11.596 L and a power output of 420 horsepower (approximately 309 kW). It is commonly used in heavy-duty trucks, tractors, and other transport vehicles, and meets the China III/Euro III emission standards.
» Ⅰ. Product Defination and Introduction:
Supplier: CEEC TRUCKS
▶ Engine Model: WP12.420E32
▶ Engine Brand: Weichai
▶ Engien Power: 309KW/420HP
▶ Displacement: 11596 ml
» Ⅱ. Product Specifications:
|
Model NO. |
WP12 .420E32 Engine |
|
Product Name |
Weichai Diesel Engine |
|
Cooling System |
Liquid-cooled |
|
Cylinder Configuration |
Inline 6-cylinder |
|
Emission Standard |
Euro 3 |
|
Engine Displacement |
11.596L |
|
Max output power |
309Kw |
|
Fuel Type |
Diesel |
|
Horsepower |
4 20 hp |
|
Total Displacement |
11.6L |
|
Rated Speed |
2 1 00r/Min |
|
Max torque |
1750N.m |
|
Minimum fuel consumption rate at full load |
185g/kW.h |
|
Exhaust Gas Treatment |
EGR Technology |
|
Intake Method |
Turbocharged Intercooled |
|
Compatible Models |
Beiben, Sinotruk , Shacman |
|
Transport Package |
Export Wooden Box |
|
Specification |
1 650 x820x1100mm |
|
W eight |
1050kg |
|
Trademark |
Weichai |
» Ⅲ. Schematic Diagram of WP12.420E32 Engine: :
|
|
» Ⅳ. Product Details:
|
|
|
|
